7.19. DISASSEMBLING THE POWER ENTRY MODULE
Figure 7.19-1
Turn the machine over on one side.
1. Back off the screws (a)
using a medium
Phillips screwdriver.
2.
Remove the power entry module plate
covering (b).
Figure 7.19-2
3. Back off the two screws (c) using a medium
Phillips screwdriver and remove the power
entry module.
4. Disconnect the cable (d)
from the power
entry module.
5. Remove the power entry module.
