Cardio WAVE EXCITE +: Service & maintenance manual - rev. 4.1
Pagina 2.14
2.9.2. CU CABLES
CU62: Power supply upper cable High Kit and Low Kit
(Patch conn. - CPU/ARM Board)
Patch conn. 1 Signal Colour
CPU Board: CN15
ARM Board: CN1
2
Gnd
White
2
3
Gnd
Yellow
3
4
- sensing +5 Vdc digital
Pink
4
6
+12Vdc
Brown
6
7
+5Vdc
Green
7
8
+sensing +5 Vdc digital
Grey
8
CU63: Serial upper cable High Kit and Low Kit
(Patch conn. - CPU/ARM Board)
Patch conn. 3 Signal Colour
CPU Board: CN18
ARM Board: CN9
1
Gnd digital
Orange-White
1
2
Gnd digital
Orange
2
3
NC
Green- White
3
4
Download
Green
4
5
Reset
Blue- White
5
6
NC
Blue
6
7
485 Tx/Rx +
Brown- White
7
8
485 Tx/Rx -
Brown
8
CU67: Power supply lower cable High Kit and Low Kit
(Brake Board – Patch conn.)
Brake Board
CN1
Signal Colour Patch conn. 1
2
Gnd
White
2
3
Gnd
Yellow
3
4
- sensing +5Vdc digital
Pink
4
6
+12Vdc
Brown
6
7
+5Vdc
Green
7
8
+sensing +5Vdc digital
Grey
8
