CU69: Serial lower cable High Kit and Low Kit
(Brake Board – Patch conn.)
Brake Board
CN3
Signal Colour Patch conn. 3
1
Gnd digital
Orange-White
1
2
Gnd digital
Orange
2
3
NC
Green- White
3
4
Download
Verde
4
5
Reset
Blue- White
5
6
NC
Blue
6
7
485 Tx/Rx +
Brown- White
7
8
485 Tx/Rx -
Brown
8
CU71: Brake power supply cable
(Brake Board – Brake – Speed Sensor – NTC)
Brake Board
CN2
Signal Colour Brake Speed Sensor NTC
1
Brake power supply +
Brown
Faston
-
-
2
Brake power supply -
Brown
Faston
-
-
3 SPM Red -
Fast-on connected
at the brawn cable
-
4
Reference SPM
Black
-
eyelet
-
5
NTC +
White
-
-
2 (Orange)
6
NTC -
White
-
-
1 (Grey)
CU110: Generator cable
(Brake Board - Generator – Battery – Battery charge input)
Brake Board
CN3
Signal Colour Generator Battery
Battery charge
input
1
V+ Tension from the
generator
Red Fast-on -
2
V- Tension from the
generator
Black Fast-on -
3
Signal RPM
White
Fast-on
4
V+ tension from
battery charge
Red -
welded at the
internal contact
5
V- tension from
battery charge
Black -
welded at the
internal contact
6
V+ Battery
Red
-
Fast-on
-
7
V- Battery
Black
-
Fast-on
-
