Cardio WAVE EXCITE +: Service & maintenance manual - rev. 4.1
Pagina 2.16
CU132: TGS signal cable
(Patch conn. – Dual TGS reader)
Patch conn. Signal Colour
Dual TGS Reader
CN1
3
+12Vdc power
Black
1
5
RX
Green
2
9
TX
Black
3
1
GND
Black
8
CU223: Touch Sensor cable / HS / HR
(ARM/CPU Board –HR/HS receiver – Touch Sensor)
(Right Touch Sensor (RED))
ARM Board:CN6
CPU Board: CN26
Signal Colour
Right
Touch sensor
1
+ 5Vdc power
White
1
2
Lever button
Brown
2
4
Reference
Green
4
(Left Touch Sensor (WHITE))
ARM Board:CN5
CPU Board: CN27
Signal Colour
Left
Touch sensor
1
+ 5Vdc power
White
1
2
Lever button
Brown
2
4
Reference
Green
4
(HS/HR cardio receiver)
ARM Board:CN4
CPU Board: CN19
Signal Colour
Cardio receiver
HR/HS:
HD4
1
+5Vdc power
Green
2
5
Out pulse
White
3
6
Reference
Brown
1
CPU Board:
CN21
Signal Colour
CPU Board:
CN19
7
GND
Black
4
CU224: Hand Sensor cable
(Cardio receiver HS/HR – Hand Sensor)
Receiver
HD3&2
Signal Colour
Hand Sensor
Right
Sup.
Right
Inf.
Left
Sup.
Left
Inf.
1
Right sensor signal
White
up
up
-
-
2
Sensors signal reference
Brown
down
down
-
-
3
GND
Shield
-
4
Left sensor signal
White
-
-
up
up
5
Sensors signal reference
Brown
-
-
down
down
6
GND
Shield
-
