TECO TP03 PLC User Manual

Instruction list
7-5
Application instruction
Step Type
Instruction type
No.
Mnemon
ic
function
16/32
Bit
P
32bit 16bit S M H
80 RS RS communications — 9 ○ ○ ○
82 ASIC HEX-ASCII 16/32
√
— 7 ○ ○ ○
83 HEX ASCII-HEX 16/32
√
— 7 ○ ○ ○
84 CCD Check code 16/32
√
— 7 ○ ○ ○
85 VRRD Volume read 16
√
— 5 — ○ ○
86 DRSC Volume scale 16
√
— 5 — ○ ○
87 MBUS MODBUS 16
√
— 11 ○ ○ ○
88 PID PID control loop 16 — 9 ○ ○ ○
External serial
devices
89 EPSC
Read scale from Expansio
n
card
16
√
— 9 — ○ ○
110 ECMP Float compare 32
√
13 — ○ ○ ○
111 EZCP Float zone compare 32
√
17 — ○ ○ ○
118 EBCD Float to scientific 32
√
9 — ○ ○ ○
119 EBIN Scientific to float 32
√
9 — ○ ○ ○
120 EADD Float add 32
√
13 — ○ ○ ○
121 ESUB Float subtract 32
√
13 — ○ ○ ○
122 EMUL Float multiplication 32
√
13 — ○ ○ ○
123 EDIV Float division 32
√
13 — ○ ○ ○
127 ESQR Float square root 32
√
9 — ○ ○ ○
129 INT Float - integer 16/32
√
9 5 ○ ○ ○
130 SIN Sine 32
√
9 — ○ ○ ○
131 COS cosine 32
√
9 — ○ ○ ○
132 TAN Tangent 32
√
9 — ○ ○ ○
133 ASIN Arc sine 32
√
9 — ○ ○ ○
134 ACOS Arc cosine 32
√
9 — ○ ○ ○
135 ATAN Arc tangent 32
√
9 — ○ ○ ○
136 RAD Degree — RAD 32
√
9 — ○ ○ ○
Floating points
and
trigonometry
137 GRE RAD — Degree 32 9 — ○ ○ ○
Data operation 147 SWAP Float to Scientific 16/32
√
5 3 ○ ○ ○
156 ZRN Zero return 16/32 17 9 — ○ ○
157 PLSV Pulse V 16/32 13 7 — ○ ○
158 DRVI Drive to increment 16/32 17 9 — ○ ○
Position
159 DRVA Drive to absolute 16/32 17 9 — ○ ○
160 TCMP Time compare 16 —— 11 — — ○
161 TZCP Time zone compare 16 —— 9 — — ○
162 TADD Time add 16 —— 7 — — ○
163 TSUB Time subtract 16 —— 7 — — ○
166 TRD Read RTC data 16
—— 3
— — ○
Real time clock
control
167 TWR Set RTC data 16 —— 3 — — ○
