TECO TP03 PLC User Manual

Chapter 2 Basic Unit Specification
3. Communication ports
2-13
*1: High speed counter address mapping
(C200~C255, 32-bit High speed counter)
Word
Register address Register value
High byte Low byte
42C8H C200 Low byte of present value Low word High byte Low word Low byte
42C9H C200 High byte of present value High word High byte High word Low byte
…… ……
4336H C255 Low byte of present value Low word High byte Low word Low byte
Present
value
4337H C255 High byte of present value High word High byte High word Low byte
6760H C200 Low byte of set value Low word High byte Low word Low byte
6761H C200 High byte of set value High word High byte High word Low byte
…… ……
67CEH C255 Low byte of set value Low word High byte Low word Low byte
Set
value
67CFH C255 High byte of set value High word High byte High word Low byte
