TECO TP03 PLC User Manual

Chapter4 Dimension and installation
Installation 4-9
Example 2:
4 75 6
OUT
PWR
0
4
0
31 2
75 6
123
IN
OE
1410
COMA
12 16
13
7
COMA
911
COMA
COMA
42
6
315
15
8
Example 3:
扩充
14
10
COMA
12
16
13
7
COMA
911
COMA
COMA
426
3
1
5
15
8
Before installing, please make sure the power is off.
Installing step for expansion cable and terminal connector:
(1) Open the expansion connector cover;
(2) Withdraw the termination connector originally installed the basic module at right side.
(3) Plug the expansion connector to the male connector on the module.
(4) Then, plug the other end connector to the male connector at left side of another module.
(5) And the termination connector should be installed in the last expansion module.
(6) Close the cover.
Cover
Prehensi on hol der
Ter mination connector
Expansi on cabl e
Expansi on socket
NOTE 1: Remove the expansion cable or termination connector from the expansion socket .
NOTE 2: Be ware of the (IN), (OUT) feature of expansion socket. They must be connected in
correct order.
expansion
> 50 mm
