The correspondence between the interface slot to the system “Line” number for the above
mixed TWOx12 is illustrated in the following table:
Slot
Designation
Channel ID #
(Telephone #)
System “Line” #
A Top1
A Top2
1 (DN/MSN 1)
1 (DN/MSN 2)
1
2
A Bot1
A Bot2
2 (DN/MSN 1)
2 (DN/MSN 2)
3
4
B1 3 5
B2 4 6
B3 5 7
C1 6 8
C2 7 9
C3 8 10
D1 9 11
D2 10 12
D3 Not Used Not Used
This table shows the relationship between the TWOx12's connectors, the Telco circuits, and the
system "line" numbers for the mixed POTS/ISDN TWOx12 described above. See section 3 for a
form you can use to organize this Information prior to programming your system.
Other than the physical interface, your system will work as usual in the above mixed
configurations. You will need to follow the information in section 2.5.1 for information
about connecting ISDN and the information in section 2.5.4 for information about
connecting analog lines.
