TELOS TWOX12 USER’S MANUAL
INSTALLATION
CHAPTER 2 47
PIN FUNCTION
1 Ground
2<Reserved>
3 Record Start Out
4 Record Stop Out
5 N/C
6<Reserved>
7 Ring Mute In
8* +5 VDC (400 mA max)
9 N/C
10 User Out (Dump)
11 Ringing Out
12 N/C
13 <Reserved>
14 <Reserved>
15 N/C
*
This power pin is in parallel
with pin 3 of the SAA ports
Note that the +5 volts DC on pin 8 is in parallel with pin 3 on both SAA ports. Failure to
limit combined current on these pins to 400mA could cause hardware damage or system
instability.
?
CURIOSITY NOTE!
The DB- designation for D- Sub connectors is from Cinch Corp’s part numbering system.
The proper Cinch designation for a 15 pin D- Sub connector is a DA- 15p (plug) or DA- 15s
(socket) not DB- 15!
Other Cinch designations for D- Sub connectors are; DE- 9, DB- 25, DC- 37 and DD- 50.
Our thanks going out to Mike Schweizer, for contributing this information.
Inputs
• The function for each input is shown on the previous page.
