PL
WYCIĄGANIE NICI ZE SZPULKI
TABELA DOBORU NICI I IGIEŁ DO SZYTEGO MATERIAŁU
1. Podnieś stopkę dociskową.
2. Przytrzymaj lekko nić od igły i przekręć kołem napędowym,
3. Wyciągnij nić od iy. Nić ze szpulki zostanie wyciągnięta nad płytkę ściegową.
Lekko pociągnij nitkę górną wyciągając tym samym dolną.
4. Umieść końwki obu nici pod stopką i wyciągnij ok. 10 cm.
Dobierz odpowiednią grubość nici i iy w zależności od rodzaju szytego materiału.
9
KNOWING YOUR SEWING MACHINE
Balancing top thread tension
The top thread and the bobbin thread
should interlock in the center of two layers
of fabric in straight seams.
Set the desired number of the thread
tension dial at setting mark.
Loosen the needle thread tension by
moving the dial to a lower number.
Tighten the needle thread tension by
moving the dial to a higher number.
NOTE: In order to obtain better zigzag stitches, the top thread tension should be
slightly weaker than the bobbin thread tension. That means, the top thread
should appear slightly on the reverse side of the fabric, but the bobbin thread
c
annot appear on the top side of the fabric.
Drawing up bobbin thread
Raise the presser foot and hold the needle thread lightly
with you left hand.
Turn the hand wheel slowly towards you with your right
hand until the needle goes down and continue turning the
hand wheel until the take-up lever is at its highest
position.
Lightly draw up the needle thread forming a loop of the
bobbin thread.
Pull 15cm (6 inches) of both thread back and under the
presser foot.
9
KNOWING YOUR SEWING MACHINE
Balancing top thread tension
The top thread and the bobbin thread
should interlock in the center of two layers
of fabric in straight seams.
Set the desired number of the thread
tension dial at setting mark.
Loosen the needle thread tension by
moving the dial to a lower number.
Tighten the needle thread tension by
moving the dial to a higher number.
NOTE: In order to obtain better zigzag stitches, the top thread tension should be
slightly weaker than the bobbin thread tension. That means, the top thread
should appear slightly on the reverse side of the fabric, but the bobbin thread
c
annot appear on the top side of the fabric.
Drawing up bobbin thread
Raise the presser foot and hold the needle thread lightly
with you left hand.
Turn the hand wheel slowly towards you with your right
hand until the needle goes down and continue turning the
hand wheel until the take-up lever is at its highest
position.
Lightly draw up the needle thread forming a loop of the
bobbin thread.
Pull 15cm (6 inches) of both thread back and under the
presser foot.
9
KNOWING YOUR SEWING MACHINE
Balancing top thread tension
The top thread and the bobbin thread
should interlock in the center of two layers
of fabric in straight seams.
Set the desired number of the thread
tension dial at setting mark.
Loosen the needle thread tension by
moving the dial to a lower number.
Tighten the needle thread tension by
moving the dial to a higher number.
NOTE: In order to obtain better zigzag stitches, the top thread tension should be
slightly weaker than the bobbin thread tension. That means, the top thread
should appear slightly on the reverse side of the fabric, but the bobbin thread
c
annot appear on the top side of the fabric.
Drawing up bobbin thread
Raise the presser foot and hold the needle thread lightly
with you left hand.
Turn the hand wheel slowly towards you with your right
hand until the needle goes down and continue turning the
hand wheel until the take-up lever is at its highest
position.
Lightly draw up the needle thread forming a loop of the
bobbin thread.
Pull 15cm (6 inches) of both thread back and under the
presser foot.
Rodzaj Materiału Grubość nici Grubość igły
Lekkie - cienka żorżeta, tafta,
jedwab itp.
Bawełniana #120 - 150
Jedwabna #120 - 150
Syntetyczna #120 - 150
70 – 80
Średnie - bawełna, len, satyna,
aksamit itp.
Bawełniana #100 - 120
Jedwabna #100 – 120
Syntetyczna #100 - 120
80 – 90
Grube - gabardyna, tweed,
denim, sztruks itp.
Bawełniana #50 - 80
Jedwabna #50 - 80
Syntetyczna #50 - 80
90 – 100
Elastyczne - dzianina, stretch,
dżersej itp.
Bawełniana #120 - 150
Jedwabna #120 - 150
80 – 90
Texi Fox 25156
