EN
TYPES OF STITCHES
STRAIGHT STITCH
STRAIGHT STRETCH STITCH
PRESSER FOOT UNIVERSAL
1. Check presser foot (universal
purpose presser foot).
2. Turn the handwheel toward
you to bring the needle to it’s
highest position.
3. Place the fabric under the
presser foot. Hold upper and
bobbin thread loosely.
4. Lower the presser foot lever and
start sewing.
5. Regulate the speed while
sewing.
6. When you reach the end of seam, press the reverse lever to sew 3-4 stitches.
7. Raise the presser foot lifter.
8. Turn the handwheel toward you to bring the needle to it’s highest position. Pull the
fabric out from under the foot to the back of the machine. Cut the threads on the
thread cutter.
PRESSER FOOT UNIVERSAL
Straight stretch stitch is far stronger
than an ordinary straight stitch
because it locks three times -
forwards, backwards and forwards.
It is particularly suitable for
reinforcing the seams of portswear
in stretch and non-stretch fabrics,
and for curved seams which take
a lot of strain. Use this stitch also to
top-stitch lapels, collars and cus to give a
professional nish to your garments.
13
UTILITY STITCHES
Straight stitch
Raise the presser foot and position the fabric next to a
stitching guide line on the needle plate.
Lower the needle into the fabric.
Lower the presser foot and smooth the thread towards the
back. Depress the foot control.
Gently guide the fabric along the guide line letting the
fabric feed by itself.
For fastening the ends of seams, press the reverse stitch
button and sew several reverse stitches.
Raise the presser foot and remove the fabric, drawing the
threads to back.
The threads are cut the proper length for starting the next
seam.
A
B
2~6
1.5~4
Machine Setting
15
UTILITY STITCHES
Tricot stitch
Place the fabric under the presser foot so
that the edge will be slightly inside the right
hand side of the presser foot.
Guide the work so the right hand stitches fall
at the edge of the fabric.
Triple strength stitch
The stitch is sewn with two stitches forward
and one stitch backward forming a seam
that does not rip easily.
Garments should be basted for fitting before
seaming.
D
1~4
0.5~1.5
Machine Setting
A B
2~6
S S
Machine Setting
15
UTILITY STITCHES
Tricot stitch
Place the fabric under the presser foot so
that the edge will be slightly inside the right
hand side of the presser foot.
Guide the work so the right hand stitches fall
at the edge of the fabric.
Triple strength stitch
The stitch is sewn with two stitches forward
and one stitch backward forming a seam
that does not rip easily.
Garments should be basted for fitting before
seaming.
D
1~4
0.5~1.5
Machine Setting
A B
2~6
S S
Machine Setting
