138
FAULT TESTING
Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
PARKING BRAKE HARD TO LATCH
Inadequate free play Adjust pedal free travel at spherical nut
and check that wheel brake actuators are
returning fully.
Sticky/dragging cable Check for brake lever return
Adjust such that brake levers return at
equal rate - (Indication of dragging cable)
Dragging shoes Check/adjust wheel brakes
PARKING BRAKE WILL NOT STAY
LATCHED
Excessive wear Check for worn latch mechanism, if neces-
sary replace the worn or damaged compo-
nents.
Condition Possible Cause Correction
To Next Page
