PARTS LISTS 6-8 Manual 0-4691
6
6.09 Right Side Internal Replacement Parts
Item # Qty Description Ref #. Catalog #
1 1 Assembly, Pressure Switch/Solenoid Sol1, Ps1 9-8329
2 1 Assembly, Pilot Board 9-8337
for (RoHS) 9-0070
3 1 Fan, 220V, 115 CFM 9-7687
4 1 Assembly, Main Transformer T5
for 208/230-Volt units 9-8345
for 400-Volt & 415-Volt units 9-8347
for 460-Volt units 9-8346
for 600-Volt units 9-8348
5 1 Assembly, Output Inductor L1 9-8591
6 1 Assembly, Output Power PCB 9-8339
for (RoHS) 9-0078
7 Assembly, Output Diode PC Board Kit 9-8349
1 Output Diode Assembly
1 Thermal Pad
for (RoHS) 9-0050
8 1 Automation Interface PC Board 9-4894
9 1 Automation Interface Wire Harness 9-4895
10 1 Transformer (only in power supplies connected to SL100SV Torch 9-9449
(with solenoid on mounting tube)
