Thermal Dynamics CUTMASTER 151 User Manual

Manual 0-4691 A-13 APPENDIX
A
APPENDIX 13: INTERFACE PCB SWITCH SETTINGS
(Division Factors 43-50)
Switch 1Switch 2Switch 3Switch 4Switch 5Switch 6Switch 7Switch 8
Divide Factor
1101001143.04
1101010043.19
1101010143.34
1101011043.48
1101011143.62
1101100043.80
1101100143.95
1101101044.08
1101101144.23
1101110044.38
1101110144.52
1101111044.66
1101111144.80
1110000045.18
1110000145.32
1110001045.46
1110001145.60
1110010045.76
1110010145.90
1110011046.04
1110011146.18
1110100046.36
1110100146.51
1110101046.64
1110101146.79
1110110046.94
1110110147.08
1110111047.22
1110111147.36
1111000047.73
1111000147.87
1111001048.01
1111001148.15
1111010048.31
1111010148.45
1111011048.59
1111011148.73
1111100048.91
1111100149.06
1111101049.19
1111101149.34
1111110049.49
1111110149.63
1111111049.77
1111111149.91
Automation Interface Switch Setting Chart, Division Factors 43 - 50
0 = DOWN = OFF, 1 = UP = ON
0 = DOWN = OFF, 1 = UP = ON
