Thermal Dynamics CUTMASTER 151 - APPENDIX 7: INTERFACE PCB SWITCH SETTINGS (MOST COMMON SETTINGS)

Manual 0-4691 A-7 APPENDIX
A
APPENDIX 7: INTERFACE PCB SWITCH SETTINGS
(MOST COMMON SETTINGS)
12345678
00000000 6.00 12.00 16.3:1
00010110 5.00 10.00 20:1
01010001 3.3 6.6 30:1
11000000 2.5 5.0 40:1
11111111 2.0 4.0 50:1
0 = DOWN = OFF, 1 = UP = ON
SW 4 SW3 SW2 SW1
Volts Out
for
100vdc In
Volts Out
for
200vdc In
Division
Factor
Factory Default Settings
Suitable for Thermal Dynamics SC-11 Standoff Control:
Other Common Settings:
0 = DOWN = OFF, 1 = UP = ON
Automation Interface Switch Setting Chart -
Common Voltage Divider Output Setting
