APPENDIX 12: INTERFACE PCB SWITCH SETTINGS
(Division Factors 36-43)
Switch 1Switch 2Switch 3Switch 4Switch 5Switch 6Switch 7Switch 8Divide Factor
1010101136.03
0111100036.16
1010110036.18
0111100136.31
1010110136.32
0111101036.44
1010111036.46
0111101136.59
1010111136.61
0111110036.74
0111110136.88
1011000036.97
0111111037.02
1011000137.11
0111111137.16
1011001037.25
1011001137.39
1011010037.55
1011010137.69
1011011037.83
1011011137.97
1011100038.15
1011100138.30
1011101038.44
1011101138.58
1011110038.73
1011110138.87
1011111039.01
1011111139.16
1100000040.07
1100000140.21
1100001040.35
1100001140.49
1100010040.64
1100010140.79
1100011040.93
1100011141.07
1100100041.25
1100100141.40
1100101041.53
1100101141.68
1100110041.83
1100110141.97
1100111042.11
1100111142.25
1101000042.62
1101000142.76
1101001042.90
Automation Interface Switch Setting Chart, Division Factors 36-43
0 = DOWN = OFF, 1 = UP = ON
0 = DOWN = OFF, 1 = UP = ON
