INTRODUCTION 2-2 Manual 0-4691
2
Power Supply Dimensions & Weight Ventilation Clearance Requirements
A-03572
27.5 in / 696 mm
12.4 in /
315 mm
17.3 in /
439 mm
83 lb / 37.6 kg
Art # A-03379
6"
150 mm
24"
0.6 m
6"
150 mm
6"
150 mm
2.03 Input Wiring Specifications
Input Power Input Current Input Suggested Sizes (See Notes)
Voltage Freq. 1-Ph 3-Ph 1-Ph 3-Ph Fuse (Amps) Wire (Non CSA) Wire (CSA)
(Volts) (Hz) (kVA) (kVA) (Amps) (Amps) 1-Ph 3-Ph 1-Ph 3-Ph 1-Ph 3-Ph
208 50 na na 4 4
208 60 20.8 na 100 na 100 4 4
230 50 na na 6 4
2306021.2na92 na100 6 4
400 50/60 19.2 48 50 8 8
400 50/60 18 26 30 10 10
460 50/60 21.1 58 60 10 10
460 50/60 19 24 30 12 12
600 60 15.6 18 20 12 12
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electrical Code
CutMaster™ 151 Input Wiring Specifications
Input Power Input Current Input Suggested Sizes (See Notes)
Voltage Freq. 1-Ph 3-Ph 1-Ph 3-Ph Fuse (Amps)
(Volts) (Hz) (kVA) (kVA) (Amps) (Amps) 1-Ph 3-Ph 1-Ph 3-Ph
400/415 50 20 48 50 10
400/415 50 11 26 30 4
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electrical Code
CE CutMaster 151 Input Wiring Specifications
Wire (mm
2
)
NOTES
Refer to Local and National Codes or local authority having jurisdiction for proper wiring requirements.
Cable size is de-rated based on the Duty Cycle of the equipment.
The suggested sizes are based on flexible power cable with power plug installations. For hard-wired installations refer
to local or national codes.
Cable conductor temperature used is 167° F (75° C).
An energy limiting fuse UL Class RK-1 (examples: BUSS LPS / LPN-RK or Gould-Shawmut AZK-A6K) should be
used to minimize damage to Plasma Cutting, Welding or power distribution equipment.
NEVER use replaceable element fuses like UL Class H, or "one-time" fuses like UL Class K5.
