APPENDIX 9: INTERFACE PCB SWITCH SETTINGS
(Division Factors 24-30)
Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8
Divide Factor
0011000024.22
0011000124.36
0011001024.50
0011001124.64
0011010024.80
0011010124.94
0011011025.08
0011011125.22
0011100025.40
0011100125.55
0011101025.69
0011101125.83
0011110025.98
0011110126.12
0011111026.26
0011111126.41
0100000027.32
0100000127.46
0100001027.60
0100001127.74
0100010027.89
0100010128.04
0100011028.18
0100011128.32
0100100028.50
0100100128.65
0100101028.78
0100101128.93
0100110029.08
0100110129.22
1000000029.31
0100111029.36
1000000129.45
0100111129.50
1000001029.59
1000001129.73
0101000029.87
1000010029.89
Automation Interface Switch Setting Chart,
Division Factors 24-30
0 = DOWN = OFF, 1 = UP = ON
0 = DOWN = OFF, 1 = UP = ON
