Thermal Dynamics CUTMASTER 151 User Manual

Manual 0-4691 A-11 APPENDIX
A
APPENDIX 11: INTERFACE PCB SWITCH SETTINGS
(Division Factors 33-36)
Switch 1Switch 2Switch 3Switch 4Switch 5Switch 6Switch 7Switch 8
Divide Factor
0110010033.01
1001100033.04
0110010133.15
1001100133.19
0110011033.29
1001101033.33
0110011133.43
1001101133.47
0110100033.61
1001110033.62
0110100133.76
1001110133.76
0110101033.89
1001111033.90
0110101134.04
1001111134.05
0110110034.19
0110110134.33
1010000034.42
0110111034.47
1010000134.56
0110111134.61
1010001034.70
1010001134.84
0111000034.98
1010010035.00
0111000135.12
1010010135.14
0111001035.26
1010011035.28
0111001135.40
1010011135.42
0111010035.56
1010100035.60
0111010135.70
1010100135.75
0111011035.84
1010101035.89
0111011135.98
Automation Interface Switch Setting Chart,
Division Factors 33 - 36
0 = DOWN = OFF, 1 = UP = ON
0 = DOWN = OFF, 1 = UP = ON
