Manual 0-4691 4-13 OPERATION
4
Cut Quality on Various Materials and
Thicknesses
The following table defines the cut quality on various mate-
rials and thicknesses:
Cut Quality on Various Materials
Material Type of Type of Cut
Thickness Material Gas Characteristics
Gage
to
Carbon Steel
Stainless
Aluminum
1.5 inch
( 38 mm )
Air
Air
Air
Good - Excellent
Good
Good
Description of Cut Characteristics:
Excellent - Minimum bevel (0 - 4°), minimum kerf (2 x tip
orifice diameter), little or no dross, smooth cut surface.
Good - Slight bevel (0 - 10°), slightly wider kerf (2-1/2 x tip
orifice diameter), some dross (easily removed), medium -
smooth cut surface, slight top edge rounding.
4.08 Cutting Specifications
Cutting Range
Material Most Metals
Up to 1 inch / 25.4 mm
Speed 10 ipm / 0.25 mpm
Pierce Rating
Material Carbon Steel
Thickness 3/8 inch / 9.5 mm
Transfer Distance
3/8 inch / 9.5 mm
Bevel Cut Capability
Degrees 0° to 45°
Material Thickness 1/2 inch - 13 mm
Gas Requirement
Type Gas Air
Operating Pressure 65 - 75psi / 4.5 - 5.2 bar
Max Input Pressure 125 psi / 8.6 bar
Total Flow 490 scfh / 231 lpm
Torch Specifications For
CutMaster 101 Power Supplies
