Manual 0-4691 4-17 OPERATION
4
NOTES
* Gas pressure shown is for torches with leads up to 25' / 7.6 m long. For 50' / 15.2 m leads, increase pressure by 5 psi / 0.34 bar.
This information represents realistic expectations using recommended practices and well - maintained systems.
Actual speeds may vary up to 50% from those shown.
Table: Dry
Gas: Compressed Air
Material thickness Tip Current
Plasma
Press.*
Pierce
Time
Arc
voltage
Stand-off
Height
Recommended
Travel Speed
In GA mm Cat. # Amps PSI In mm SEC Volts in mm IPM mm/min
0.038 20 1.0 8-8208 40 65 0.2 4.8 0.00 103 0.19 4.80 357 9067.8
0.050 18 1.3 8-8208 40 65 0.2 4.8 0.00 104 0.19 4.80 287 7289.8
0.063 16 1.6 8-8208 40 65 0.2 4.8 0.10 104 0.19 4.80 244 6197.6
0.078 14 2.0 8-8208 40 65 0.2 4.8 0.30 105 0.19 4.80 125 3175.0
0.135 3.4 8-8208 40 65 0.2 4.8 0.40 105 0.19 4.80 106 2692.4
0.141 10 3.6 8-8208 40 65 0.2 4.8 0.50 106 0.19 4.80 104 2641.6
0.188 4.8 8-8208 40 65 0.2 4.8 0.60 106 0.19 4.80 75 1905.0
0.250 6.4 8-8208 40 65 0.2 4.8 1.00 109 0.19 4.80 46.6 1183.6
0.375 9.5 8-8208 40 65 NR NR NR 109 0.19 4.80 31.5 800.1
0.500 12.7 8-8208 40 65 NR NR NR 112 0.19 4.80 17.4 442.0
0.625 15.9 8-8208 40 65 NR NR NR 114 0.19 4.80 10 254.0
0.063 16 1.6 9-8210 60 70 0.2 4.8 0.00 107 0.19 4.80 177 4495.8
0.078 14 2.0 9-8210 60 70 0.2 4.8 0.10 108 0.19 4.80 169 4292.6
0.125 11 3.2 9-8210 60 70 0.2 4.8 0.10 109 0.19 4.80 140 3556.0
0.135 3.4 9-8210 60 70 0.2 4.8 0.10 110 0.19 4.80 117 2971.8
0.141 10 3.6 9-8210 60 70 0.2 4.8 0.15 111 0.19 4.80 103 2616.2
0.188 4.8 9-8210 60 70 0.2 4.8 0.20 112 0.19 4.80 90 2286.0
0.250 6.4 9-8210 60 70 0.2 4.8 0.30 113 0.19 4.80 68.8 1747.5
0.375 9.5 9-8210 60 70 0.2 4.8 0.50 115 0.19 4.80 35 889.0
0.500 12.7 9-8210 60 70 0.2 4.8 0.75 121 0.19 4.80 21.3 541.0
0.625 15.9 9-8210 60 70 NR NR NR 127 0.19 4.80 15.9 403.9
0.750 19.1 9-8210 60 70 NR NR NR 131 0.19 4.80 12.5 317.5
1.000 25.4 9-8210 60 70 NR NR NR 135 0.19 4.80 6 152.4
0.048 18 1.2 9-8211 80 65 0.2 4.8 0.05 102 0.19 4.80 411 10439.4
0.125 11 3.2 9-8211 80 65 0.2 4.8 0.05 104 0.19 4.80 291 7391.4
0.135 3.4 9-8211 80 65 0.2 4.8 0.10 105 0.19 4.80 270 6858.0
0.188 4.8 9-8211 80 65 0.2 4.8 0.20 106 0.19 4.80 171 4343.4
0.250 6.4 9-8211 80 65 0.2 4.8 0.30 107 0.19 4.80 88 2235.2
0.375 9.5 9-8211 80 65 0.2 4.8 0.40 111 0.19 4.80 47 1193.8
0.500 12.7 9-8211 80 65 0.2 4.8 0.60 113 0.19 4.80 28.8 731.5
0.625 15.9 9-8211 80 65 0.2 4.8 0.75 117 0.19 4.80 19.5 495.3
0.750 19.1 9-8211 80 65 NR NR NR 120 0.19 4.80 15.6 396.2
0.875 22.2 9-8211 80 65 NR NR NR 123 0.19 4.80 12 304.8
1.000 25.4 9-8211 80 65 NR NR NR 126 0.19 4.80 10 254.0
1.250 31.8 9-8211 80 65 NR NR NR 130 0.19 4.80 6 152.4
0.250 6.4 9-8212 100 70 0.2 4.8 0 104 0.19 4.8 134 3.4
0.375 9.5 9-8212 100 70 0.2 4.8 0 110 0.19 4.8 67 1701.8
0.500 12.7 9-8212 100 70 0.2 4.8 0 113 0.19 4.8 40 1016.0
0.750 19.1 9-8212 100 70 0.2 4.8 0 118 0.19 4.8 22 558.8
1.000 25.4 9-8212 100 70 0.2 4.8 NR 123 0.19 4.8 12 304.8
1.250 31.8 9-8212 100 70 0.2 4.8 NR 129 0.19 4.8 9 228.6
1.500 38.1 9-8212 100 70 0.2 4.8 NR 135 0.19 4.8 6 152.4
Material: Stainless Steel
Pierce Height
Torch: SL100 with Exposed Tip and Deflector
Power Supply: CutMaster 151 Automated
