Manual 0-4691 4-21 OPERATION
4
NOTES
* Gas pressure shown is for torches with leads up to 25' / 7.6 m long. For 50' / 15.2 m leads, increase pressure by 5 psi / 0.34 bar.
This information represents realistic expectations using recommended practices and well - maintained systems.
Actual speeds may vary up to 50% from those shown.
Torch
Tip
Shield
Cap
Current
Plasma
Pre ss.*
Pierce
Time
Arc
voltage
In GA mm Cat. # Cat. # Amps PSI In mm SEC Volts in mm IPM mm/min
0.036 20 0.9144 8-8208 9-8245 40 65 1.88 4.8 0.00 102 0.19 4.80 170 4318
0.051 1.30 8-8208 9-8245 40 65 1.88 4.8 0.00 103 0.19 4.80 148 3759.2
0.060 16 1.52 8-8208 9-8245 40 65 1.88 4.8 0.10 104 0.19 4.80 133 3378.2
0.075 14 1.91 8-8208 9-8245 40 65 1.88 4.8 0.30 106 0.19 4.80 95 2413
0.135 10 3.43 8-8208 9-8245 40 65 1.88 4.8 0.40 110 0.19 4.80 65 1651
0.188 4.78 8-8208 9-8245 40 65 1.88 4.8 0.60 113 0.19 4.80 30 762
0.250 6.35 8-8208 9-8245 40 65 1.88 4.8 1.00 117 0.19 4.80 23 584.2
0.375 9.53 8-8208 9-8245 40 65 NR NR NR 126 0.19 4.80 10 254
0.500 12.70 8-8208 9-8245 40 65 NR NR NR 122 0.19 4.80 7 177.8
0.625 15.88 8-8208 9-8245 40 65 NR NR NR 135 0.19 4.80 3 76.2
0.060 16 1.57 9-8210 9-8238 60 70 1.88 4.8 0.00 117 0.19 4.80 235 5969
0.075 14 1.91 9-8210 9-8238 60 70 1.88 4.8 0.10 118 0.19 4.80 190 4826
0.120 11 3.05 9-8210 9-8238 60 70 1.88 4.8 0.10 118 0.19 4.80 218 5537.2
0.135 10 3.43 9-8210 9-8238 60 70 1.88 4.8 0.10 119 0.19 4.80 142 3606.8
0.188 4.78 9-8210 9-8238 60 70 1.88 4.8 0.20 120 0.19 4.80 117 2971.8
0.250 6.35 9-8210 9-8238 60 70 1.88 4.8 0.30 123 0.19 4.80 66 1676.4
0.375 9.53 9-8210 9-8238 60 70 1.88 4.8 0.50 119 0.19 4.80 34 863.6
0.500 12.70 9-8210 9-8238 60 70 1.88 4.8 0.75 121 0.19 4.80 23.4 594.36
0.625 15.88 9-8210 9-8238 60 70 NR NR NR 135 0.19 4.80 14 355.6
0.750 19.05 9-8210 9-8238 60 70 NR NR NR 130 0.19 4.80 13.6 345.44
1.000 25.40 9-8210 9-8238 60 70 NR NR NR 135 0.19 4.80 12.8 325.12
0.047 18 0.05 9-8211 9-8239 80 65 1.88 4.8 0.00 104 0.19 4.80 231 5867.4
0.120 11 0.13 9-8211 9-8239 80 65 1.88 4.8 0.10 106 0.19 4.80 173 4394.2
0.135 3.43 9-8211 9-8239 80 65 1.88 4.8 0.10 106 0.19 4.80 165 4191
0.188 7 4.78 9-8211 9-8239 80 65 1.88 4.8 0.20 103 0.19 4.80 125 3175
0.250 6.35 9-8211 9-8239 80 65 1.88 4.8 0.30 113 0.19 4.80 82 2082.8
0.375 9.53 9-8211 9-8239 80 65 1.88 4.8 0.40 118 0.19 4.80 38 965.2
0.500 12.70 9-8211 9-8239 80 65 1.88 4.8 0.60 115 0.19 4.80 29.6 751.84
0.625 15.88 9-8211 9-8239 80 65 1.88 4.8 0.75 123 0.19 4.80 19 482.6
0.750 19.05 9-8211 9-8239 80 65 NR NR NR 128 0.19 4.80 14 355.6
0.875 22.23 9-8211 9-8239 80 65 NR NR NR 134 0.19 4.80 11 279.4
1.000 25.40 9-8211 9-8239 80 65 NR NR NR 129 0.19 4.80 9.2 233.68
1.250 31.75 9-8211 9-8239 80 65 NR NR NR 134 0.19 4.80 5 127
0.250 6.4 9-8212 9-8239 100 70 0.19 4.8 0 104 0.19 4.80 121 3073.4
0.375 9.5 9-8212 9-8239 100 70 0.19 4.8 0 110 0.19 4.80 54 1371.6
0.500 12.7 9-8212 9-8239 100 70 0.19 4.8 0 113 0.19 4.80 40 1016
0.750 19.1 9-8212 9-8239 100 70 0.19 4.8 0 118 0.19 4.80 22 558.8
1.000 25.4 9-8212 9-8239 100 70 0.19 4.8 NR 121 0.19 4.80 11 279.4
1.250 31.8 9-8212 9-8239 100 70 0.19 4.8 NR 128 0.19 4.80 8 203.2
1.500 38.1 9-8212 9-8239 100 70 0.19 4.8 NR 133 0.19 4.80 6 152.4
Pierce Height
Recommended
Travel speed
Stand-off
Height
Material thickness
Gas: Compressed Air
Material: Mild Steel
Torch: SL100 with Shielded Tip
Power Supply: CutMaster 151 Automated
Table: Dry
