Thermal Dynamics CUTMASTER 151 User Manual

Manual 0-4691 4-23 OPERATION
4
NOTES
* Gas pressure shown is for torches with leads up to 25' / 7.6 m long. For 50' / 15.2 m leads, increase pressure by 5 psi / 0.34 bar.
This information represents realistic expectations using recommended practices and well - maintained systems.
Actual speeds may vary up to 50% from those shown.
Torch
Tip
Shield
Cap
Current
Plasma
Pre ss.*
Pierce
Time
Arc
voltage
In GA mm Cat. # Cat. # Amps PSI In mm SEC Volts in mm IPM mm/min
0.038 20 8-8208 9-8245 40 65 0.2 4.8 0.00 109 0.19 4.8 179 4546.6
0.050 18 1.3 8-8208 9-8245 40 65 0.2 4.8 0.00 109 0.19 4.8 150 3810
0.063 16 1.6 8-8208 9-8245 40 65 0.2 4.8 0.10 110 0.19 4.8 122 3098.8
0.078 14 2.0 8-8208 9-8245 40 65 0.2 4.8 0.30 111 0.19 4.8 66 1676.4
0.135 3.4 8-8208 9-8245 40 65 0.2 4.8 0.40 111 0.19 4.8 66 1676.4
0.141 10 3.6 8-8208 9-8245 40 65 0.2 4.8 0.50 112 0.19 4.8 65 1651
0.187 4.7 8-8208 9-8245 40 65 0.2 4.8 0.60 112 0.19 4.8 38 965.2
0.250 6.4 8-8208 9-8245 40 65 0.2 4.8 1.00 116 0.19 4.8 23 584.2
0.375 9.5 8-8208 9-8245 40 65 NR NR NR 116 0.19 4.8 16 406.4
0.500 12.7 8-8208 9-8245 40 65 NR NR NR 119 0.19 4.8 9 228.6
0.625 15.9 8-8208 9-8245 40 65 NR NR NR 121 0.19 4.8 5 127
0.063 16 1.6 9-8210 9-8238 60 70 0.2 4.8 0.00 113 0.19 4.8 142 3606.8
0.078 14 2.0 9-8210 9-8238 60 70 0.2 4.8 0.10 115 0.19 4.8 134 3403.6
0.125 11 3.2 9-8210 9-8238 60 70 0.2 4.8 0.10 116 0.19 4.8 112 2844.8
0.135 3.4 9-8210 9-8238 60 70 0.2 4.8 0.10 118 0.19 4.8 82 2082.8
0.141 10 3.6 9-8210 9-8238 60 70 0.2 4.8 0.15 118 0.19 4.8 82 2082.8
0.187 4.7 9-8210 9-8238 60 70 0.2 4.8 0.20 119 0.19 4.8 75 1905
0.250 6.4 9-8210 9-8238 60 70 0.2 4.8 0.30 120 0.19 4.8 55 1397
0.375 9.5 9-8210 9-8238 60 70 0.2 4.8 0.50 122 0.19 4.8 28 711.2
0.500 12.7 9-8210 9-8238 60 70 0.2 4.8 0.75 128 0.19 4.8 17 431.8
0.625 15.9 9-8210 9-8238 60 70 NR NR NR 135 0.19 4.8 13 330.2
0.750 19.1 9-8210 9-8238 60 70 NR NR NR 139 0.19 4.8 10 254
1.000 25.4 9-8210 9-8238 60 70 NR NR NR 142 0.19 4.8 4 101.6
0.052 18 0.0 9-8211 9-8239 80 65 0.2 4.8 0.00 108 0.19 4.8 329 8356.6
0.125 11 9-8211 9-8239 80 65 0.2 4.8 0.00 110 0.19 4.8 233 5918.2
0.135 3.4 9-8211 9-8239 80 65 0.2 4.8 0.10 111 0.19 4.8 220 5588
0.172 4.4 9-8211 9-8239 80 65 0.2 4.8 0.20 112 0.19 4.8 137 3479.8
0.250 6.4 9-8211 9-8239 80 65 0.2 4.8 0.30 113 0.19 4.8 71 1803.4
0.375 9.5 9-8211 9-8239 80 65 0.2 4.8 0.40 118 0.19 4.8 38 965.2
0.500 12.7 9-8211 9-8239 80 65 0.2 4.8 0.60 120 0.19 4.8 23 584.2
0.625 15.9 9-8211 9-8239 80 65 0.2 4.8 0.75 124 0.19 4.8 16 406.4
0.750 19.1 9-8211 9-8239 80 65 NR NR NR 127 0.19 4.8 12 304.8
0.875 22.2 9-8211 9-8239 80 65 NR NR NR 130 0.19 4.8 10 254
1.000 25.4 9-8211 9-8239 80 65 N
R
N
R
N
R
134 0.19 4.8 8 203.2
0.250 6.4 9-8212 9-8239 100 70 0.2 4.8 0 104 0.19 4.8 125 3175
0.375 9.5 9-8212 9-8239 100 70 0.2 4.8 0 110 0.19 4.8 64 1625.6
0.500 12.7 9-8212 9-8239 100 70 0.2 4.8 0 113 0.19 4.8 40 1016
0.750 19.1 9-8212 9-8239 100 70 0.2 4.8 0 118 0.19 4.8 18 457.2
1.000 25.4 9-8212 9-8239 100 70 0.2 4.8 NR 121 0.19 4.8 10 254
1.250 31.8 9-8212 9-8239 100 70 0.2 4.8 NR 128 0.19 4.8 6 152.4
1.500 38.1 9-8212 9-8239 100 70 0.2 4.8 NR 133 0.19 4.8 5 127
Material: Stainless Steel
Torch: SL100 with Shielded Tip
Power Supply: CutMaster 151 Automated
Table: Dry
Gas: Compre sse d Air
Recommended
Travel Speed
Stand-of
f
Heigh
t
Pierce HeightMaterial thickness
