Thermal Dynamics CUTMASTER 151 User Manual

Manual 0-4691 4-25 OPERATION
4
NOTES
* Gas pressure shown is for torches with leads up to 25' / 7.6 m long. For 50' / 15.2 m leads, increase pressure by 5 psi / 0.34 bar.
This information represents realistic expectations using recommended practices and well - maintained systems.
Actual speeds may vary up to 50% from those shown.
Torch
Tip
Shield
Cap
Current
Plasma
Press.*
Pierce
Time
Arc
voltage
In GA mm Cat. # Cat. # Amps PSI In mm SEC Volts in mm IPM mm/min
0.04 20 1.0 8-8208 9-8245 40 65 0.2 4.8 0.00 100 0.19 4.8 220 5588.0
0.051 1.3 8-8208 9-8245 40 65 0.2 4.8 0.00 102 0.19 4.8 220 5588.0
0.064 16 1.6 8-8208 9-8245 40 65 0.2 4.8 0.10 104 0.19 4.8 220 5588.0
0.079 14 2.0 8-8208 9-8245 40 65 0.2 4.8 0.30 108 0.19 4.8 149 3784.6
0.125 3.2 8-8208 9-8245 40 65 0.2 4.8 0.35 112 0.19 4.8 73 1854.2
0.135 3.4 8-8208 9-8245 40 65 0.2 4.8 0.40 115 0.19 4.8 69 1752.6
0.187 4.7 8-8208 9-8245 40 65 0.2 4.8 0.60 118 0.19 4.8 50 1270.0
0.250 6.4 8-8208 9-8245 40 65 0.2 4.8 1.00 122 0.19 4.8 25 635.0
0.375 9.5 8-8208 9-8245 40 65 NR NR NR 129 0.19 4.8 11 279.4
0.500 12.7 8-8208 9-8245 40 65 NR NR NR 134 0.19 4.8 7 177.8
0.625 15.9 8-8208 9-8245 40 65 NR NR NR 138 0.19 4.8 4 101.6
0.034 22 1.6 9-8210 9-8238 60 70 0.2 4.8 0.00
101 0.19 4.8 352 8940.8
0.064 16 1.6 9-8210 9-8238 60 70 0.2 4.8 0.10 105 0.19 4.8 352 8940.8
0.125 3.2 9-8210 9-8238 60 70 0.2 4.8 0.10 109 0.19 4.8 352 8940.8
0.135 3.4 9-8210 9-8238 60 70 0.2 4.8 0.10 112 0.19 4.8 272 6908.8
0.141 3.6 9-8210 9-8238 60 70 0.2 4.8 0.15 118 0.19 4.8 220 5588.0
0.187 4.7 9-8210 9-8238 60 70 0.2 4.8 0.20 122 0.19 4.8 136 3454.4
0.250 6.4 9-8210 9-8238 60 70 0.2 4.8 0.30 126 0.19 4.8 76 1930.4
0.375 9.5 9-8210 9-8238 60 70 0.2 4.8 0.50 129 0.19 4.8 46 1168.4
0.500 12.7 9-8210 9-8238 60 70 0.2 4.8 0.75 136 0.19 4.8 28 711.2
0.625 15.9 9-8210 9-8238 60 70 NR NR NR 139 0.19 4.8 19 482.6
0.750 19.1 9-8210 9-8238 60 70 NR NR NR 142 0.19 4.8 14 355.6
1.000 25.4 9-8210 9-8238 60 70 NR NR NR 150 0.19 4.8 4 101.6
0.047 18 0.0 9-8211 9-8239 80 65 0.2 4.8 0.00
107 0.19 4.8 335 8509.0
0.125 0.1 9-8211 9-8239 80 65 0.2 4.8 0.10 107 0.19 4.8 241 6121.4
0.135 3.4 9-8211 9-8239 80 65 0.2 4.8 0.10 107.0 0.19 4.8 225 5715.0
0.187 4.7 9-8211 9-8239 80 65 0.2 4.8 0.20 107 0.19 4.8 146 3708.4
0.250 6.4 9-8211 9-8239 80 65 0.2 4.8 0.30 114 0.19 4.8 99 2514.6
0.375 9.5 9-8211 9-8239 80 65 0.2 4.8 0.40 122 0.19 4.8 52 1320.8
0.500 12.7 9-8211 9-8239 80 65 0.2 4.8 0.60 125 0.19 4.8 36 914.4
0.625 15.9 9-8211 9-8239 80 65 0.2 4.8 0.75 130 0.19 4.8 26 660.4
0.750 19.1 9-8211 9-8239 80 65 NR NR NR 135 0.19 4.8 16 406.4
0.875 22.2 9-8211 9-8239 80 65 NR NR NR 148 0.19 4.8 8 203.2
1.000 25.4 9-8211 9-8239 80 65 NR NR NR 164 0.19 4.8 4 101.6
1.250 31.8 9-8211 9-8239 80 65 NR NR NR 170 0.19 4.8 2 50.8
0.250 6.4 9-8212 9-8239 100 70 0.2 4.8 0 104 0.19 4.8 148 3759.2
0.375 9.5 9-8212 9-8239 100 70 0.2 4.8 0 110 0.19 4.8 118 2997.2
0.500 12.7 9-8212 9-8239 100 70 0.2 4.8 0 113 0.19 4.8 79 2006.6
0.750 19.1 9-8212 9-8239 100 70 0.2 4.8 0 118 0.19 4.8 31 787.4
1.000 25.4 9-8212 9-8239 100 70 0.2 4.8 NR 121 0.19 4.8 18 457.2
1.250 31.8 9-8212 9-8239 100 70 0.2 4.8 NR 128 0.19 4.8 14 355.6
1.500 38.1 9-8212 9-8239 100 70 0.2 4.8 NR 133 0.19 4.8 11 279.4
Material: Aluminum
Torch: SL100 with Shielded Tip
Power Supply: CutMaster 151 Automated
Table: Dry
Gas: Compressed Air
Pierce Height
Recommended
Travel Speed
Stand-off
Height
Material thickness
