Thermo 48i - Page 111

Operation
Alarms Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-89
• In the Main Menu, choose Alarms > Internal Temp.
• Use and to move the cursor up and down.
• Press to select a choice.
• Press to return to the Alarms menu or to return to the
Run screen.
Min and Max Internal
Temperature Limits
The Minimum Internal Temperature alarm limit screen is used to change
the minimum internal temperature alarm limit. The minimum and
maximum internal temperature screens function the same way.
• In the Main Menu, choose Alarms > Internal Temp > Min or Max.
• Use and to increment or decrement the numeric value.
• Press to save set to value as actual value.
• Press to return to the Internal Temperatures menu or to
return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
INTERNAL TEMPERATURE:
ACTUAL 30.1
o
C
>MIN 8.0
o
C
MAX 47.0
o
C
RANGE AVG DIAGS ALARM
