Thermo 48i - Communication Settings

Operation
Instrument Controls Menu
Thermo Electron Corporation Model 48i Instruction Manual 3-41
Communication Settings The communication Settings menu is used with communications control
and configuration.
• In the Main Menu, choose Instrument Controls> Communication
Settings.
• Use and to move the cursor up and down.
•Press to accept a choice.
• Press to return to the Instrument Controls menu or to
return to the Run screen.
Baud Rate The Baud Rate screen is used to set the RS-232/RS-485 interface baud rate.
Baud rates of 1200, 2400, 4800, and 9600, 19200, 38400, 57600, and
115200 are available.
• In the Main Menu, choose Instrument Controls > Communication
Settings > Baud Rate.
• Use and for a list of choices.
•Press to save the new baud rate.
• Press to return to the Communication Settings menu or
to return to the Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
COMMUNICATION SETTINGS:
>BAUD RATE
INSTRUMENT ID
COMMUNICATION PROTOCOL
STREAMING DATA CONFIG
RS-232/RS-485 SELECTION
TCP/IP SETTINGS
RANGE AVG DIAGS ALARM
