Operation
Display
3-2 Model 48i Instruction Manual Thermo Electron Corporation
Display The 320 x 240 graphics liquid-crystal display (LCD) shows the sample
sample concentrations, instrument parameters, instrument controls, help,
and error messages. Some menus contain more items than can be displayed
at one time. For these menus, use and to move the cursor up
and down to each item.
Figure 3-1. 48i Front Panel Display
CAUTION If the LCD panel breaks, do not let the liquid crystal contact your
skin or clothes. If the liquid crystal contacts your skin or clothes, wash it off
immediately using soap and water.

