Operation
Alarms Menu
3-90 Model 48i Instruction Manual Thermo Electron Corporation
Bench Temperature The Bench Temperature screen displays the current bench temperature and
sets the minimum and maximum alarm limits. Acceptable alarm limits
range from 40 to 59 °C. If the bench temperature reading goes beyond
either the minimum or maximum limit, an alarm is activated. The word
“ALARM” appears in the Run screen and in the Main Menu.
• In the Main Menu, choose Alarms > Bench Temp.
• Use and to move the cursor up and down.
• Press to select a choice.
• Press to return to the Alarms menu or to return to the
Run screen.
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
INTERNAL TEMPERATURE:
ACTUAL MIN: 30.1
o
C
SET MIN TO: 10.0
o
C ?
©ª
INC/DEC
SAVE VALUE
RANGE AVG DIAGS ALARM
XXLO WCONCENTRATIONXXLO W
CO 15.80 PPM
SAMPLE 12:34 ALARMx
BENCH TEMPERATURE:
ACTUAL 48.4
o
C
>MIN 40.0
o
C
MAX 59.0
o
C
RANGE AVG DIAGS ALARM
