Introduction
Specifications
1-4 48i Instruction Manual Thermo Electron Corporation
Power requirements 100 VAC @ 50/60 Hz
115 VAC @ 50/60 Hz
220–240 VAC @ 50/60 Hz
275 watts
Physical dimensions 16.75” (W) X 8.62” (H) X 23” (D)
Weight Approximately 49 lbs.
Analog outputs 6 voltage outputs; 0–100 mV, 1, 5, 10 V (User selectable), 5% of
full-scale over/under range, 12 bit resolution, user selectable for
measurement input
Digital outputs 1 power fail relay Form C, 10 digital relays Form A, user selectable
alarm output, relay logic, 100 mA @ 200 VDC
Digital inputs 16 digital inputs, user select programmable, TTL level, pulled high
Serial Ports 1 RS-232 or RS-485 with two connectors, baud rate 1200–115200,
data bits, parity, and stop bits, protocols: C-Link, MODBUS, and
streaming data (all user selectable)
Ethernet connection RJ45 connector for 10Mbs Ethernet connection, static or dynamic
TCP/IP addressing
*
In non condensing environments. Performance specifications based on operation with 20–30 °C range.
