Troubleshooting
Connector Pin Descriptions
6-18 Model 48i Instruction Manual Thermo Electron Corporation
5 Ground
6 Ground
7 SPI Reset
8 SPI Input
9 SPI Output
10 SPI Board Select
11 SPI Clock
DIGITAL
OUTPUTS
J2 1 Relay 1 Contact a
2 Relay 2 Contact a
3 Relay 3 Contact a
4 Relay 4 Contact a
5 Relay 5 Contact a
6 Relay 6 Contact a
7 Relay 7 Contact a
8 Relay 8 Contact a
9 Relay 9 Contact a
10 Relay 10 Contact a
11 NC
12 Solenoid Drive Output 1
13 Solenoid Drive Output 2
14 Solenoid Drive Output 3
15 Solenoid Drive Output 4
16 Solenoid Drive Output 5
17 Solenoid Drive Output 6
18 Solenoid Drive Output 7
19 Solenoid Drive Output 8
20 Relay 1 Contact b
21 Relay 2 Contact b
22 Relay 3 Contact b
23 Relay 4 Contact b
24 Relay 5 Contact b
25 Relay 6 Contact b
Table 6-7. Digital Output Board Connector Pin Descriptions, continued
Connector
Label
Reference
Designator
Pin Signal
Description
