C-Link Protocol Commands
Datalogging
Thermo Electron Corporation Model 48i Instruction Manual B-17
Send: list stream
Receive: list stream
field index variable
x x time
1 10 auxt
2 13 pres
3 14 smplfl
4 15 intensity
er xy
lr xy
sr xy
x = | 0 | 1 | : Reply termination format (see “set format format”
command)
y = | 0 | 1 | 2 | : Output format (see “set erec/lrec/srec format format”
command)
These commands report the last long and short records stored or the
dynamic data record. In the example below, the command requests a long
record with no checksum, in ASCII format with text. For details on how to
decode the flag fields within these records, see the “flags” command.
Send: lr01
Receive: lr01
10:15 05-12-03 flags 9c040000 co 7349E+0 loco 5994E+0 intt
33.2 cht 44.7 pres 758.9 smplfl 1.085 speed 100.0 biasv
-115.5 intensity 1999940
erec
This command returns a brief description of the main operating conditions
at the time the command is issued (i.e. dynamic data). The example below
shows a typical response. The format is defined by the current settings of
“format” and “erec format” commands. For details on how to decode the
flag fields within these records, see the “flags” command.
Send: erec
Receive: erec
09:48 04-06-05 flags 9C040510 co 0.000 4 loco -0.002 4
s/r 0.000 los/r 0.902 biasv -112.668 agci 96.500 intt 34.023
cht 47.995 smpfl 0.000 pres 0.000 avgt1 10 avgt2 10 cobkg
-0.000 cocoef 1.000 lococoef 1.000 corange 10000000.000
locorange 10000000.000 motor 100.000
lrec
srec
lrec xxxx yy
srec xxxx yy
lrec aa:bb oo-pp-qq yy
srec aa:bb oo-pp-qq yy
