C-Link Protocol Commands
Datalogging
Thermo Electron Corporation Model 48i Instruction Manual B-19
set lrec format format
set srec format format
These commands set the output format for long and short records, and
dynamic data, according to Table B-4. The example below sets the long
record output format to ASCII with text.
Send: set lrec format 1
Receive: set lrec format 1 ok
erec layout
lrec layout
srec layout
These commands report the layout (string indicating the data formats) for
data that is sent out in response to the erec, lrec, srec, and related commands
For details on how to interpret the strings, see “Record Layout Definition”
later in this appendix.
Send: lrec layout
Receive: lrec layout %s %s %lx %f %f %f %f
t D L ffff
s/r pres intensity motor
lrec mem size
srec mem size
These commands report the long and short records that can be stored with
the current settings and the number of blocks reserved for long and short
records. To calculate the number of short records per block, add 2 to the
number of records, and then divide by the number of blocks. The example
below shows that 10 blocks were reserved for long records, and the
maximum number of long records that can be stored in memory is 2038.
Send: lrec mem size
Receive: lrec mem size 2038 recs, 10 blocks
lrec per
srec per
These commands report the long and short records logging period. The
example below shows that the short record logging period is 5 minutes.
Table B-4. Record Output Formats
Format Output Format
0 ASCII no text
1 ASCII with text
2 binary data
