TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 27 Flight Controls
Page 104 Issue: 11.AUG 2016
▶ Remove the aileron.
Installation
▶ Install in reverse sequence of removal.
▶ Check aileron for free movement.
▶ Check function of NAV/strobe light.
▶ Check function of aileron trim (RH aileron only) on both control sticks.
▶ Main switch OFF
27-10-02 Aileron Trim
The control of the right aileron´s trim tab is provided by an electric
servo operated by trim buttons, located on both control sticks. The
aileron’s trim tab position is indicated on both Dynon Skyview
instruments within the EMS panel.
27-20 Rudder Control
The rudder is controlled via a pair of control cables. They are routed
from the rudder pedal linkage through the center of the fuselage to
the tail. There they penetrate the left and right fuselage side walls and
are connected to the rudder crank arms. The rudder travel stops are
located on the side of the fuselage tail next to the rudder crant arms.
They are riveted to the fuselage tail structure.
The rudder pedals are adjustable (short pilot/tall pilot) for left and
right side individually. The adjustment is done by pulling rudder pedal
extensions outwards and rotating them towards the pilot seat.
The rudder horn is only aerodynamically used.
