TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 24 Electrical Power
Page 94 Issue: 11.AUG 2016
24 Electrical Power
24-00 General
The electrical system is a 12V DC system.
The system consists of
AC generator with rectifier
Battery
Fuses
Circuit breakers
Switches
Indication lights
For wiring overview and partial diagrams refer to Chapter
91 Charts
and also Chapter
00-10 List of Figures
.
24-30 DC Generation
24-30-10 Generator
The electrical system is supplied by an in-built AC generator with a
rectifier (12 V/22 A DC). This generator is part of the engine
installation (refer to Rotax documentation).
24-30-20 Battery
The battery (VARTA 519901017) is an auxiliary source of electric
energy, located in the engine compartment on the left lower side of
the firewall. It is accessible after the removal of the upper engine
cowling.
The cockpit is equipped with an on-board 12V electric socket, located
on the right instrument panel. The socket can be used for charging of
the aircraft battery.
