TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 20 Standard Practices-Airframe
Page 90 Issue: 11.AUG 2016
Fitting, joint with
incise ring and
interposition hose
(Kašpar)
20-10-04 Bowden Cables
Removal
▶ Note position of cable tie.
▶ Remove cable tie.
▶ Disconnect Bowden cable from actuator arm.
▶ Remove firewall seal from firewall penetration.
▶ Unscrew firewall penetration plastic grommet.
▶ Loosen the counternut of control knob.
▶ Pull out the Bowden cable.
Installation
▶ Install in reverse sequence of removal.
▶ Seal firewall penetration with PR 812 sealant.
▶ Check correct travel. Adjust travel if necessary.
