TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter57 Wing
Page 170 Issue: 28.FEB 2017
57-30 Wing Tips
57-30-01 Wing Tip Fairing
The wing tips are equipped with composite wingtip fairings. The wing
tip fairings are attached to the wing by means of rivets.
Removal
▶ Remove rivets as per Chapter 20-10-02 Rivets.
▶ Disconnect electrical wiring of NAV/strobe light.
▶ Remove wing tip fairing
Installation
Install in reverse sequence of removal.
57-50 Flaps
The flaps are an all-metal design with a main spar.
57-60 Ailerons
The ailerons are an all-metal design. The right aileron features a trim
motor support and a trim tab.
