TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter75 Air
Page 178 Issue: 28.FEB 2017
75-40 Indicating
75-40-01 Coolant Temperature
The thermal sensors are located on the 2nd and 3rd cylinder heads.
Electric signals from sensors are led by cables to the Dynon system.
The temperature of coolant (one reading for each cylinder head) is
indicated on EMS screen.
