TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 27 Flight Controls
Issue: 11.AUG 2016 Page 105
Figure 10 Rudder control
27-20-01 Rudder
The rudder is connected to the respective vertical stabilizer brackets
by means of two ball bearings.
The rudder features to crank arms on its bottom, which are connected
to the rudder control Bowden cables.
