TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 06 Dimensions and Areas
Page 70 Issue: 11.AUG 2016
06 Dimensions and Areas
06-00 General
06-00-01 Coordinate System
The level attitude is defined by the horizontal orientation of the
canopy frame.
06-10 Main Data
06-10-01 External Dimensions
Length: 6.400 m
Height: 2.200 m
Wing span: 8.340 m
06-10-02 Wing
Area: 10.450 m
2
Wing chord 1.290 m
Aspect ratio: 6.6
Wing profile: NACA 4415
Wing platform: rectangular
Incidence angle: 3
Dihedral: 3
Sweep angle: 0
Wing twist: 0
06-10-03 Aileron
Area: (each) 0.260 m
2
Span: (each) 0.960 m
Chord: 0.270 m
