TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter32 Landing Gear
Page 124 Issue: 11.AUG 2016
▶ Place a jack under the nose gear attachment bracket, so that the nose
wheel is 5 cm from ground as per Chapter
07-10-02 Jacking the
Aircraft Front
.
▶ Remove wheel fork attachment bolt and remove wheel fork.
Installation
▶ Install in reverse sequence of removal.
32-20-04 Shock Cord Ring
Replacement
Refer to Figure 19.
The following procedure consists of these main elements:
Getting access to the nose gear strut
Removal of nose gear wheel fork to be able to install the rod and cup
mountings (refer to Figure 52) and tensioning tools.
Releasing the shock cord ring tension by means of the tensioning
tools.
Changing the shock cord rings.
