TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 31 Indication & Recording Systems
Issue: 11.AUG 2016 Page 119
31-00-01 Panel
Removal
The left, central and right panel sometimes has to be removed to get
access to the department in front of it. However generally the panels
can be tilted back without the need for disconnecting the electrical
wirings of instruments, switches and circuit breakers. The wiring
length is designed to allow this.
NOTICE Scratches possible on the instrument panel structure.
▶ Protect the instrument panel surface e.g. by means of tape.
▶ Remove attaching screws.
▶ Tilt back the panel as far as necessary to get access to the cable ties.
▶ Note position of cable ties.
▶ Cut cable ties where necessary to be able to tilt back the panel as
needed.
▶ Tilt back the panel and fix in position with tape.
Installation
▶ Install in reverse sequence of removal.
31-00-02 Typical Instruments
Removal
▶ Switch off aircraft power.
▶ Remove control knob if applicable.
▶ Tilt the applicable panel back as per Chapter
31-00-01 Panel
.
▶ Disconnect cable and/or sense line from instrument.
▶ Remove screws, nuts or clipnuts as applicable.
▶ Remove instrument from panel.
Installation
▶ Install in reverse sequence of removal.
