TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 71 Power Plant
Page 172 Issue: 28.FEB 2017
71 Power Plant
71-00-01 Top Engine Cowling
Removal
▶ Release camlocks.
▶ Push top engine cowling ~2 cm forward.
▶ Remove top engine cowling upward.
Installation
▶ Place top engine cowling on the edge of the bottom engine cowling.
▶ Stick the bayonet pins of the top cowling into the pear-shaped holes
of the bottom cowling.
▶ Align the aft dowel pins to the holes in the firewall.
▶ Push the top cowling ~2 cm aft.
▶ Lock camlocks.
71-00-02 Bottom Engine Cowling
Carry out the following procedures with to persons.
Removal
▶ Support the bottom engine cowling.
▶ Remove Allen screws.
▶ Remove the bottom engine cowling.
Installation
▶ Place the bottom engine cowling to its correct place and support it.
▶ Install Allen screws.
