TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 53 Fuselage
Issue: 28.FEB 2017 Page 163
53 Fuselage
The airplane’s fuselage is made as an all-metal monocoque frame
structure, comprising stringers and aluminium alloy skin.
The vertical stabiliser is an integral part of the fuselage.
The engine compartment is separated from the crew compartment by
a steel covered bulkhead firewall.
Figure 31 Fuselage
