TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 53 Fuselage
Page 164 Issue: 28.FEB 2017
53-00-01 Canopy
A clear canopy covers the cockpit. It opens up and backwards. Two
gas springs located on the outboard sides of the luggage
compartments support the canopy during opening and closing action.
Two independent levers located on the both sides of the canopy are
used to lock it.
The following parts are integrated in the canopy and its frame (also
refer to Figure 5):
Canopy air inlets,
air vents
control valves
locking levers and
canopy windows.
For canopy sealing a rubber profile is glued on the fuselage frame
below the canopy.
53-00-02 Fuseage Tail Fairing
The fuselage tail fairing is attached to the structure by means of Allen
screws.
