TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 06 Dimensions and Areas
Page 72 Issue: 11.AUG 2016
Root Chord: 1.122 m
Tip Chord: 0.587 m
Platform: trapeze
Profile NACA 0010
06-10-10 Rudder
Area: 0.560 m²
Leading edge sweep angle: 35
Trailing edge sweep angle: 11
06-10-11 Fuel System
Fuel tank capacity: 2 x 50 litres
06-10-12 Landing Gear
Track width: 2.190 m
Wheel base: 1.270 m
Main wheels: 4.00 – 6 (Kašpar K-226A-000 6’’)
Nose wheel: 4.00 – 6 (Kašpar K-116A-000 6’’)
06-10-13 Propeller
Number of blades: 3
Diameter: 1.650 m
