TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter32 Landing Gear
Issue: 11.AUG 2016 Page 129
32-40-03 Brake Cylinder
Removal
NOTICE Brake fluid can damage paint or other material.
▶ Cover the affected areas with appropriate clothes.
▶ Clean up immediately spilt brake fluid.
▶ Remove the brake cylinder mounting plate from the vertical part of
control panel (4 Allen screws).
▶ Pull the assembly some centimeters aft.
▶ Disconnect the choke control knob from the mounting plate
(1 counter nut).
▶ Pull out the brake cylinder about 20 cm.
▶ Disconnect the brake line (1 nut).
▶ Remove brake cylinder from mounting plate (4 bolts).
Installation
Install in reverse sequence of removal.
32-40-04 Brake
Removal
▶ Remove main wheel from aircraft as per Chapter
▶
32-40-02 Main
Wheel.
▶ Remove brake from main wheel (1 central nut).
Installation
Install in reverse sequence of removal.
Disassembly
▶ Remove brake from main wheel as per above paragraph.
▶ Note position of wheel axle.
▶ Remove wheel axle (1 set screw).
▶ Remove brake lining backing plate (1 rod with securing clip each
side).
▶ Disassemble brake.
