TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 55 Stabilizers
Issue: 28.FEB 2017 Page 167
55-30 Vertical Stabilizer
The vertical stabilizer is an all metal, single-piece design of a trapeze
platform, with an auxiliary/rear spar.
On its top a composite fin tip is installed.
The VS rear spar features two brackets for the rudder attachment.
Figure 33 Vertical stabilizer
55-40 Rudder
The rudder is an all-metal design with an aerodynamically used
composite rudder horn.
