TOMARK Viper SD-4 RTC - Page 137

TOMARK, s.r.o.
Airplane Maintenance Manual
Chapter 51 Standard Practices Structure
Issue: 28.FEB 2017 Page 137
Item
Description
Item
Description
1
Access hatch
9
Bottom engine cowling
2
Fuel filler cap
10
Oil hatch
3
Wing tip fairing
11
Wing root fairing (left and right)
4
Spinner
12
Tail skid cover
5
Main wheel fairing
13
Horizontal stabilizer tip fairing
(left and right)
6
Nose gear strut fairing
14
Fuselage tail fairing
7
Nose wheel fairing
15
Antennas inspection cover
8
Top engine cowling
16
Vertical stabilizer tip fairing
Removal/Installation Information
for
refer to Chapter
Top engine cowling
71-00-01 Top Engine Cowling
Bottom engine cowling
71-00-02 Bottom Engine Cowling
Fuselage Tail Fairing
53-00-02 Fuseage Tail Fairing
Main wheel fairing
32-40-01 Main Wheel Fairing
Nose gear strut fairing
32-20-01 Nose Gear Strut Fairing
Nose wheel fairing
32-20-02 Nose Wheel Fairing
Wing root fairing
57-10-01 Wing Root Fairing
Wing tip fairings
57-30-01 Wing Tip Fairing
Stabilizer tip fairings
55-00-01 Stabilizer Tip Fairings
Spinner
61-10-02 Spinner
