Battery and Charger
MERGE 11-27
Chapter 11
void the warranty.
b) Securely fasten the black ring terminal from the charger to the negative terminal“.”,
“NEG”,NEGATIVE”) of the battery pack.
c) Check that the correct charge algorithm is being used –refer to section 4).Securely fasten the
red ring terminal to the positive terminal (“+”,“POS”, “POSITIVE”) of the battery pack.
Mechanical
All models
Dimensions 28.0*24.5*11.0cm(11*9.7*4.3)”
Weight <5kg(<11lbs) w/ standard output cord
Environmental Enclosure:IP46
Operating Temperature -30 to +50 (℃℃-22to 122),℉℉ derated
Above 30 ,below 0℃℃
Storage Temperature -40 to +70 (℃℃-40 to 158 )℉℉
AC input connector IEC320/C14(require>=1.8m localized cord)
DC output connector OEM specific w/ 12AWG wire
Regulatory
Safety
EN 60335-1/2-29 Safely of Appliances/Battery Chargers
UL2202 EV Charging System Equipment
UL1564 2nd Edition Industrial Battery Charger
CSA-C22.2 No.107-2 Battery Chargers-Industrial
Emissions
FCC Part 15/ICES 003 Unintentional Radiators Class A
EN 55011 Radio disturbance characteristics(Class A)
EN 61000-3-2 Limits for harmonic current emissions
EN 61000-3-3 Limits of voltage fluctuations and flicker
Immunity
EN 61000-4-2 Electrostatic discharge immunity
EN 61000-4-3 Radiated, radio -frequency, EMF immunity
EN 61000-4-4 Electrical fast transient/burst immunity
EN 61000-4-5 Surge immunity
EN 61000-4-6 Conducted Immunity
EN 61000-4-11 Voltage variations immunity
