Steering System
EMERGE 8-2
Chapter 8
Removal of the Steering System
1. Park the vehicle on level ground.
2. Apply the parking brake.
3. Put a suitable bracket under the frame and lift
up the front wheels with lifting jack.
Refer to Chapter 1 "Recommendation for Use
of Lifting Jack".
4. Remove:
· Steering wheel cover plate
· Steering wheel nuts ②
· Steering wheel ③
5. Remove:
· Dashboard
Please refer to Chapter 4 "Removal of the
Dashboard".
· Disconnect the connecting line of turn signal
stalk
·Sleeve of turn signal stalk cable
· Bolt
· Turn signal stalk
6. Remove:
· Upper fixing bolt of the block of steering
column ①
Tightening torque
20N·m (14.8 ft·1b)
· Lower fixing nut of the block of steering
column ②
To Next Page
